SIMPLY PUT. OUR BRIDGE IS FAR SUPERIOR TO THE COMPETITION.

SHOP NOW

BASS BRIDGE

01.

MAXIMIZES THE TRANSFER OF STRING-TO-BODY VIBRATIONS

02.

GIVES YOUR BASS EXEPTIONAL BRIGHTNESS & CLARITY

03.

FULLY ADJUSTABLE WITH SECURE CLAMP & LOCK SYSTEM

04.

MADE FROM NON-CORROSIVE AIRCRAFT ALUMINUM

05.

CONTINUALLY MAINTAINS TONAL INTEGRITY

06.

FITS BOTH STRING-THROUGH & TOP LOAD DESIGNS

WHAT IS IT?

Imagine the perfect bridge for a solid body stringed instrument. It would have to be rock solid with no moving parts and no parts to vibrate. The set up would have the optimal playing height for each individual player and a huge amount of string contact to allow string tone to absorb into the body of the instrument and make the instrument sound whole. I envisioned one solid chunk of metal, but the problems are obvious; non-adjustment and weight.

The KSM Foundation™ Bass Bridge was designed to achieve the benefits of a single solid piece, but also to be fully adjustable for each individual player. The bridge utilizes a patented ramp system that allows for precise adjustments and maximizes the transfer of string-to-body vibrations. This improved string-to-body contact gives the instrument exceptional brightness and clarity.

The KSM Foundation™ Bass Bridge is designed to be installed on many new or used bass guitar brands, such as: Fender, Ibanez, Spector, BC Rich, Jackson and Tune Guitar Technology. The bridge is also favored by builders and luthiers that require the best style and tone for their instruments. Please call or email if you have any questions regarding any of our products.
The KSM Foundation™ Bass Bridge is born to achieve the benefits of a solid mass, but also have adjustabilty. It utilizes a patented ramp system that allows precise adjustablility and maximizes string contact to saddles. The ramp and adjustment bolts lock into position to prevent any part from moving after final adjustments are made. The weight issue is solved by using a very strong aircraft aluminum which is also a very resonant material. The KSM Foundation™ bridge is the best on the market for what it does. It sets notes free!

BASS OF THE WEEK

Here's an awesome custom bass build by Wayne Wheatley featuring our KSM Foundation Bass Bridge!!! This bass has a beautiful Canadian quilted Maple top and Koah back. It's rocking two quarter pounder Seymour Duncan pickups and Ernie Ball electronics. "I like the KSM bridge because it's solid, easy to install, and the set up is straight forward. Each guitar I have used them on has amazing sustain and the tone is remarkable." Visit our shop to give your bass an amazing boost!

lightning

30-DAY MONEY-BACK GUARANTEE

If you’re not completely satisfied with your Foundation Bass Bridge you can return it. No questions, no hassle, no problems.
rocks

LIFETIME WARRANTY

The KSM Foundation™ Bass Bridge is guaranteed to be free from manufacturing defects in materials and craftsmanship.

IMPROVE YOUR SUSTAIN AND TONE.

SHOP NOW

FOR ALL YOU NERDS, HERE'S THE SPECS.

  • Both String-Through Body or Top Load Design
  • Anodized Black (or) Nickel Plated 6061-T6 aluminum
  • .468” minimum string height - bottom of string to top of bass body
  • .703” maximum string height - bottom of string to top of bass body
  • String Spacing: .750” center to center
  • Intonation adjustment range: .750” front to back
  • Footprint: 3.500” x 2.250”
  • Frame Height: .437”
  • Intonation and lock bolt wrench (included)
  • Ramp height adjustment wrench (included)
  • High-strength mounting screws (included)
  • Weight: 4.25 oz

* The size of the allen wrenches used for bridge adjustments are 1.5 metric for the height adjustment, and 2.5 metric for the lock down and intonation adjustments.

  • Both String-Through Body or Top Load Design
  • Anodized Black 6061-T6 aluminum
  • .437” minimum string height - bottom of string to top of bass body
  • .656” maximum string height - bottom of string to top of bass body
  • String Spacing: 18mm/.718"  & 17mm/.669 center to center
  • Intonation adjustment range: .750” front to back
  • Footprint: 4.125” x 2.250”
  • Frame Height: .437”
  • Intonation and lock bolt wrench (included)
  • Ramp height adjustment wrench (included)
  • High-strength mounting screws (included)
  • Weight: 5.30 oz

MOST BASS BRIDGES VS. KSM FOUNDATION BASS BRIDGE

yes_no-2
about_bridge_01
about_bridge_02
about_bridge_03
about_bridge_04

UNIQUE DESIGN FEATURES OF THE KSM FOUNDATION BASS BRIDGE.

bass_bridge_exploded

INSTALL ON VIRTUALLY ANY BASS

screw

SEE THE ATTACHMENT SCREW PATTERNS

CHECK EM OUT
play

SEE HOW TO INSTALL THE BRIDGE

WATCH THE VID
target

WE EVEN HAVE INSTALLATION TEMPLATES

DOWNLOAD TEMPLATES

GET A ROCK SOLID BASS BRIDGE.

SHOP NOW
quote
I thought the difference would be subtle compared to a stock "classic" bridge. I was wrong! Instantly noticeable, notes have more clarity and far better sustain. This combined with locking in my intonation and action. I’m sold.
- Scot Alexander, Dishwalla
